Screw Sand Washing Machine
Screw Sand Washing Machine Inquiry

The screw sand washing machine is mainly used for sand processing, electric pole factory, building work site and concrete dam, various sands classifying and dewatering. This machine has three functions: washing, dewatering, classifying.

Technical data
Model Spiral Diameter (mm) Number of Spiral (pcs) Feeding Size (mm) Capacity (t/h) Water Consumption (m3/h) Motor Power (kw) Overall Dimensions (mm) Weight (t)
XL-762 762 1 <10 75 9-63 11 9070×2650×1530 5.20
2XL-762 762 2 <10 140 20-150 2×11 9070×3250×1530 7.45
XL-914 914 1 <10 100 10-80 15 9070×2650×1638 6.35
2XL-914 914 2 <10 200 60-300 2×15 9070×3510×1638 11.30
XL-1118 1118 1 <10 175 13-168 22 9070×2830×1900 12.70
2XL-1118 1118 2 <10 350 60-600 2×22 9070×3890×1900 16.50
Note: Any change of Screw Sand Washing Machine technical data shall not be advised additionally.
Features

● High degree cleaning-up;
● Reasonable structure;
● Large capacity;
● Low power consumption.

Application
Screw Sand Washing Machine From China
