Combined Separator
Combined Separator Inquiry

1. In minerals: used for magnetite, pyrrhotite, franklinite, hematite, magnetic hematite, titanium magnetite, siderite, chromite and other weakly magnetic minerals sorting.
2. Raw materials applications: used for the purification of kaolin, feldspar, quartz, zircon ore, etc and the separation of iron in all kinds of material with high granularity.
3. Recycling: mainly used to get valuable material in smelting slag .

Technical data
Model Magnetic Cylinder( Roller) Size (Ф×L) Magnetic Cylinder ( Roller) Agnetic Induction GS Magnetic Cylinder ( Roller) Rotation Speed (r/min) Capacity (t/h) Motor Power (Kw) Grain Size (MM) Weight (Kg)
ZTLDST3G-10 Cylinder 1 400×1000 Cylinder 1 ≥7000 Cylinder 1 150 9~11 3 ≤3 1600
Roller 1 100×1000 Roller 2 ≥12000 Roller 2 200
Roller 2 100×1000 Roller 3 ≥12000 Roller 3 150 2.2 3~18
Roller 3 150×1000 Roller 3 ≥14000 Roller 3 100
Note: Any change of Combined Separator technical data shall not be advised additionally.
Features

1. This machine is used for sorting 0.4-16mm grain size magnetic minerals. On the basis of the magnetic separation feasibility, through a combination of design, it put distributed beneficiation processes into centralized beneficiation processes to significantly improve the efficiency and grade of ore beneficiation.
2. The overall design of the machine facilitates modular production. Cage screen and belt conveyor can be installed and connected on the machine directly so that it forms a perfect dressing assembly line from conveying to the screening, from screening to magnetic separating.
3. Combined magnetic separator adopts permanent magnet system design, it functions stably, and the concentrate grade can be guaranteed.
4. According to the mineral particle size, the whole machine adopts left and right magnetic system design. Left part of machine ensure mineral optional granularity less than 2.5mm; beneficiation grain size is 2.5mm to 16mm at right part of machine; the mineral particles larger than 16 mm cannot enter the magnetic system for sorting.
5. The whole structure is simple, transmission part is bare style outside the machine body to achieve quick maintenance and overhaul in the production process.
6. This machine adopts electrical control technology to make production operation convenient and easy, at the same time improve efficiency and reduce the operator's labor intensity.

Application
Combined Separator From China
