40-60 TPH
40-60 TPH Inquiry

The 40-60 TPH Jaw & Impact Crushing Plant includes vibrating feeder GZD850X3000, jaw crusher PE500X750, impact crusher PF1010, vibrating screen 3YZS1548, belt conveyor and centrally electric controlling system, etc.

The 40-60 TPH Jaw & Cone Crushing Plant includes vibrating feeder GZD850X3000, jaw crusher PE500X750, cone crusher PYB900, vibrating screen 3YZS1548, belt conveyor and centrally electric controlling system, etc. The designed capacity is from 40t/h to 60t/h. To meet customer’s specific requirement, we can also add other equipments such as impact crusher, dust catcher on the crushing plant.

Technical data

40-60TPH JAW & CONE CRUSHING PLANT

NO. equipment model qty.
Vibrating Feeder GZD850*3000 1
Jaw Crusher PE500*750 1
PY Spring Cone Crusher PYB900 1
Vibrating Screen 3YZS1548 1
Belt Conveyor B500*18M 1
Belt Conveyor B500*18M 1
Belt Conveyor B500*20M 1
Belt Conveyor B500*16M 1
Belt Conveyor B500*16M 1
Belt Conveyor B500*16M 1

40-60TPH JAW & IMPACT CRUSHING PLANT

NO. equipment model qty.
Vibrating Feeder GZD850*3000 1
Jaw Crusher PE500*750 1
Impact Crusher PF1010 1
Vibrating Screen 3YZS1548 1
Belt Conveyor B500*15M 1
Belt Conveyor B500*18M 1
Belt Conveyor B500*20M 1
Belt Conveyor B500*16M 1
Belt Conveyor B500*16M 1
Belt Conveyor B500*16M 1
Note: Any change of 40-60 TPH technical data shall not be advised additionally.
Process

Big materials are fed to the jaw crusher PE500*750 evenly and gradually by vibrating feeder GZD850*3000 through a hopper for primary crushing. After first crushing, the material will transferred to cone crusher PYB900 by belt conveyor B500*18M for secondary crush; the crushed materials will then transferred to vibrating screen 3YZS1548 for separating. After being separated, the parts that can meet standard will be taken away as final products, while the other parts will be returned to impact crusher, thus forming a closed circuit. Size of final products can be combined and graded according to customer's specific requirement. We can also equip dust catcher system to protect environment.

Application
