Jaw Crusher
Jaw Crusher Inquiry

The Oriental Jaw Crusher is widely used in mining, building materials, chemical industry, metallurgy and so on. The Jaw Crusher is suitable for primary and secondary crushing all kinds of minerals and rocks with compressive strength less than 320 MPa.

Technical data
  Model Feed Opening Size (mm) Max. Feeding Size (mm) Adjustable Range of Output Size (mm) Capacity (t/h) Motor Power (kw) Weight (t) Overall Dimension (mm)
PE250×400 250×400 200 20-50 5-20 15 2.9 1430×1310×1340
PE400×600 400×600 350 40-100 15-60 30-37 6.8 1700×1732×1653
PE500×750 500×750 425 50-100 40-100 45-55 11.2 2035×1921×2000
PE600×900 600×900 480 65-160 60-140 55-75 16.5 2290×2206×2370
PE750×1060 750×1060 630 80-150 80-230 90-110 29 2655×2302×3110
PE900×1200 900×1200 750 95-165 140-320 110-132 54.5 3789×3050×3025
PE1000×1200 1000×1200 850 105-185 180-400 160-200 56.5 3900×3320×3280
PE1200×1500 1200×1500 1020 150-300 250-800 220-250 99.6 4300×3540×4043
PEX150×250 150×250 125 10-40 1-3 5.5 0.85 896×745×935
PEX150×750 150×750 125 12-45 5-16 15 3.8 1205×1495×1203
PEX250×750 250×750 210 25-60 10-40 22-30 5 1667×1545×1020
PEX250×1000 250×1000 210 25-60 15-50 30-37 6.8 1964×1550×1380
PEX250×1200 250×1200 210 25-60 20-60 37-45 8.5 2192×1605×1415
Note: The capacity above is tested as per medium hard limestone.
Any change of Jaw Crusher technical data shall not be advised additionally.
Features

● Simple structure, easy maintenance;
● High crushing ratio, even output granularity;
● High reliability, low investment;
● Low noise, less dust.

Application
Jaw Crusher From China
