Impact Crusher
Impact Crusher Inquiry

The Impact Crusher is used for primary, secondary and fine crushing of all kinds of stones and rocks with compressive strength less than 350 MPa such as granite, marble, and limestone. The Impact Crusher is widely used for sand and rock production in the industry of roads, railways, reservoir, electricity power, building materials and so on.

Technical data
Model Rotor Size(mm) Feed Opening Size(mm) Max. Feeding Size(mm) Capacity(t/h) Motor Power (kw) Weight (t) Overall Dimension(mm)
PF-1007 ø1000×700 400×730 250 15-50 37-55 9.5 2400×1560×2660
PF-1010 ø1000×1050 400×1080 300 50-80 55-75 13.2 2440×2250×2630
PF-1210 ø1250×1050 400×1080 300 70-130 110-132 16.5 2700×2340×2870
PF-1214 ø1250×1400 400×1430 300 90-180 132-160 19.5 2700×2695×2900
PF-1315 ø1320×1500 860×1520 350 120-250 180-260 24.8 2860×2800×3050
PF-1320 ø1320×2000 860×2030 500 160-350 300-375 30 2870×3350×3090
Note: The capacity above is tested as per medium hard limestone.
Any change of Impact Crusher technical data shall not be advised additionally.
Features

● Cubic-shaped end products;
● Adjustable end products sizes, simple crushing process;
● The board hammer is made of high chrome and, abrasion-resistant, and with powerful impacting force;
● Non-key connected, easy to maintain, cost-saving;
● Sound construction and high efficiency.

Application
Impact Crusher From China
