Oriental-Drum Screen

Drum Screen Inquiry

ZGT series drum screen renewal product on the basis of the old drum screen, it overcomes the problem of mesh plug when circular vibrating screen and line screen are screening wet material, to improve the yield and reliability of the screening system. It is mainly used for grading large and small stones in the quarry, separate sand and gravel in the sand and gravel plant, separate lump coal and pulverized coal in the coal industry and washes coal (part of coal washing machinery) in chemical industry; classify different sizes of lumps and separate powder substance in mineral processing industry. It also can be used to desliming and dewatering in the material with large mud content.

Technical data

Model	Capacity (t/h)	Power (kw)	Cylinder Diameter (mm)	Cylinder Length (mm)	Screen Mesh Size (mm)	Dimensions (mm)	Weight (kg)
ZGT1015	50	4.0	1000	1500	<3～10	300014002145	2200
ZGT1020	100	5.5	1000	2000		346014002145	2800
ZGT1225	160	7.5	1200	2500		414616002680	4200
ZGT1530	250	11	1500	3000		446019002820	5100
ZGT1545	350	15	1500	4500		596019003080	6000
ZGT1848	450	22	1800	4800		650023004000	7500
ZGT2055	600	30	2000	5500		750025004000	8600

Note: Any change of Drum Screen technical data shall not be advised additionally.

Features

1. Wide adaptability of feeding
Drum Screen is widely used in various types of materials screening, whether it is of low quality coal, or bituminous coal, and other class materials, can be successfully carried out the screening.
2. The feed manners are simple and diverse
The feeding port of drum screen developed by our company can be set according to the actual design, whether its belt, funnel or other ways to feed, do not take special measures to smoothly feed.
3. High screening efficiency
The device can be equipped with comb-type ballast cleaning institution, in the screening process, it can screen no matter how dirty and multi-hybrid materials come into the sieve tube, thereby increasing the screening efficiency of the device.
4. The screen amount is large, and easy to be large-scale
In the same size, the area of a circle is larger than other shapes, so their screening effective area is larger, and material can be fully contact with the screen, thus the screen amount per unit time is larger. And for its simple structure, convenient layout, the technology is new and mature, is vulnerable to large-scale.
5. Energy consumption
The motor power of drum screen developed by our company is low, half to one-third of the other screens, and the running time is only half of the other screen in dealing with the same amount of materials, so the energy consumption is low.
6. The working environment is good
Throughout the screening process is equipped with the scouring water, completely remove the dust flying and massive splash phenomena in the screening cycle process, avoid pollution of the work environment.
7. The noise of device is low
8. The life is long life, and the maintenance is simple
The drum screen is composed of some circular ring networks, its total screening area is far greater than the other sieve-screening area, coupled with high efficiency, and the operating time is short, therefore it is of a longer service life, less wearing parts, small amount of maintenance
9. Easy to maintenance
The device can be opened (except for special parts), which does not affect the normal operation of the machine, and the maintenance is very convenient.
